M5 * 0.8 - 8mm Stainless Steel Key - Locking Thread Insert Heavy
Duty Type 303
Information
The key-locking thread insert is a special fastener with threads
inside and outside, and four or two bolt keys on the outer thread.
The bolt screw is set into the bottom hole after tapping, and then
the four bolts are pressed in to achieve Strong fastening effect.
From the appearance of the product, the bolt sleeve can be divided
into thin-wall type and heavy-duty type. There are also reinforced
and extra-heavy types. The products are mainly used in military
industry, aerospace, railway locomotives, vibration machinery and
other products that require high thread strength.
Classification
1. According to Thread Types, it can be divided into: Metric, UNC
coarse thread, UNF fine thread.
2. According to the Insert Types screw sleeve model, it can be
divided into: Miniature light type, Lightweight (Thinwall) thin
wall type, Heavy Duty heavy duty, Extra Heavy Duty heavy duty.
Advantage
- The key locking-type threaded sheath can be firmly locked on the
female material
- Reduce friction during installation
- Anti-corrosion
- Shorter repair time
- No special tools required
Specification
| Thread inserts type | Metric thread inserts |
| Material | Stainless Steel 303 |
| Size | M5 * 0.8 - 8mm |
| Package | small pack+Carton+Pallet |
| Surface Treatment | Natrual |
| Sample | Available |
| Place of Origin | Henan,china |
| Product Name | key locking threaded insert |
| INTERNAL | EXTERNAL | LENGTH(mm) |
|
| M5*0.8P | M8*1.25P | 8 |
| M6*1.0P | M10*1.25P | 10 |
| M8*1.0P | M12*1.25P | 12 |
| M8*1.25P | M14*1.5P | 12 |
| M10*1.0P | M14*1.5P | 14 |
| M10*1.25P | M14*1.5P | 14 |
| M10*1.5P | M14*1.5P | 14 |
SUPPLY MANY KINDS OF THREADED INSERT NUTS
WELCOME TO CONSULT US THE PRICE AND OTHER SIZE.
Xinxiang Flight Fastener Co., Ltd. is a professional manufacturer
engaged in the design and manufacture of Thread Inserts, Self-Tapping thread inserts and other threaded fasteners.
National high-tech enterprises. The company has independent
technology development strength, advanced design level, automatic
production equipment and high precision detection equipment.
Professional to provide customers with Thread Inserts, Self-Tapping
thread inserts and other threaded fastener product design and use
of the whole process of technical support.
FAQ
Q: How long is your delivery time?
A: We have large stock, 3 days for stock items,7-15days for
production
.
Q: Do you provide samples? Is it free or need extra fees ?
A: Yes, we could offer free samples for the items in stock,just
need to pay shipping cost. Mold fee is necessary for customized item.
Q: What is your terms of payment ?
A: 50% in advance ,50% before delivery.100% in advance if less than USD5000.
Q: What's your price terms ?
A: EXW/FOB/CIF/CFR/FCA/CPT/CIP/DAP/DDP
Q: Are you trading company or manufacturer ?
A: We are manufacturer.
